Shuar Logboat at National Museum of Ecuador

Following a two-year closure caused by money problems and the need for extensive renovation, the National Museum of Ecuador at La Casa de Cultura in Quito reopened last Saturday. The essentially new museum is attractive, sophisticated, and free.

In the current fashion of most museums, this one takes pains to tell stories. Artifacts are displayed in service of narratives constructed by the curators (and, one suspects, by the museum's board of directors and management). This means that one might not find an extensive display of items from a particular culture or artistic movement all in one place. Instead, one or a few such items might appear in a conceptually linear display with different types of items from different eras, movements, or cultures, in order to illustrate, for example, the evolution of a national identity, art movement, or economy, the widespread effects of colonialism, racism, or nationalism, or some other major theme. In terms of public education and opinion-shaping, this is probably a good approach, but for visitors interested in a particular, narrow subject, it can be disappointing or frustrating. Count me in the latter group, even while I acknowledge that the museum is a fine one and well worth a visit.

I was there on opening day (ticket #36) and went searching for boat-related content. In this post we'll look at one notable item, a beautiful 20th century logboat (i.e., dugout canoe) of the Shuar people of Ecuador's Amazonian region, on loan from Museo Pumapungo in Cuenca, Ecuador. (We posted previously about another Shuar logboat of a different design on display in Quito.) As always, click any image to enlarge it.


Shuar dugout canoe
The Shuar logboat is about 17' LOA with a narrow beam of about 15.5". Type of wood was not identified. (Dimensions are either eyeballed or based on armspan and handspan measurements.)
Shuar dugout canoe
The sides are straight and parallel. The ends are virtually identical, leading to square-ended  extensions or platforms.

Shuar dugout canoe
The interior sections are rather square. Sides and bottom are flat and at very close to right angles. The sides are about 7/8" thick at the sheer. The bottom is roughly 1.5" - 1.75" thick.

Shuar dugout canoe
The platforms/extensions are fairly narrow, rising out of thickened "gunwales" near the ends. A slight ridge appears on the underside of the platform.


Shuar dugout canoe end view
The exterior of the hull shows rounded chines and a flat bottom. A single bent nail appears sticking out to the right of the end extension/platform. It does not appear to be robust enough to serve as a tying-off point. Might it be a guide for a fishing line?
Shaur logboat detail
Even while the sides and bottom retain a sharp angle between them, the interior hollowing tapers and rises to a sharp point, leaving a large amount of timber intact at the ends. This visually appealing feature probably helps the hull resist cracking.

Shuar dugout canoe adze marks
The boat was hollowed out using an adze, marks from which are clearly visible.

Shuar dugout canoe decoration
Applied decoration near one end does not appear to be paint. Perhaps it is derived from a plant resin (?).

Shuar dugout canoe decoration
Decoration near midships. Ax and/or adze marks can be seen on the exterior of the hull.

Shuar dugout canoe paddle
The paddle is about 5'6" long, but the upper end of the shaft is missing, along with any end-grip that may have existed (unlikely). The shaft and blade are carved from the whole. The shaft is flat on its front and back surfaces, but the sides are rounded and the edges are relieved. The blade has wide shoulders and tapers toward a broadly rounded tip.
